Introduction
Parameter
|
Diameter |
Pitch |
Inside Width |
Outside Width |
Inner Length |
Weight |
Working Load Limit |
Proof Load |
Breaking Load |
|||
|
d |
Tolerance |
P |
Tolerance |
b1 min. |
b2 max. |
11 x p |
Tolerance |
(kg/m) |
WLL |
MPL |
MBL |
|
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(mm) |
(KN) |
(KN) |
(KN) |
|
|
10 |
±0.4 |
50 |
+0.8/-0.4 |
14.0 |
36.0 |
550.0 |
+3.9/-2.2 |
1.8 |
10 |
25 |
50 |
|
13 |
±0.5 |
65 |
+1.0/-0.5 |
18.2 |
46.8 |
715.0 |
+5.0/-2.9 |
3.1 |
16 |
40 |
80 |
|
16 |
±0.6 |
80 |
+1.3/-0.6 |
22.4 |
57.6 |
880.0 |
+6.2/-3.5 |
4.7 |
25 |
63 |
125 |
Standards
